Skyfold Classic - for maximum versatility
The Classic™ Series was developed to meet the acoustic challenges of geometrically variable spaces from the simple (offices, classrooms) to the complex (auditoriums with sloped and stepped floors).
Individually designed for flexibility of use
Skyfold Classic can be adapted individually to almost any layout and is suitable for use in straightforward or complex floor plans. The Classic series is also ideal for rooms with stepped or sloping floors, or a combination of the two as often found in auditoriums and academic environments. The flexibility of the Skyfold system allows the multifunctional use of valuable space.
Space-saving design retracts to the ceiling
The space-saving vertical movable wall system retracts to the underside of the ceiling or into a specially provided ceiling cavity. When parked, the system merges harmoniously and almost invisibly with the ceiling. In addition to better use of space, the Skyfold also enhances facility appearance as no lateral guide or floor rails are required.
Rapid and reliable operation
At the touch of a button, a mechanism inside the insulated double-skin Skyfold folds and retracts the movable wall quickly, reliably and fully automatically at a speed of 1.5 to 3 m/min. Ceiling motors retract the movable wall completely along its entire length. Built-in sensors on the lower edge ensure that the system stops in the presence of an obstruction when descending.
Features
- A space-saving vertical movable wall system that retracts into the ceiling to maximise floor space
- Acoustic ratings up to Rw 59 dB
- No floor, wall tracks or visible hinges
- Fully automatic
- Easy to usre turn-key, or digital keypad operation
- Quiet operation
- Lightweight panels
- Flat and rigid
- Lightweight structure
- Variety of finish options
- Can be installed to meet at 900
- Can be used in stepped or sloped spaces
- Equipped with a safety obstructiuon sensor
- Made to last
Surface finishes
- Laminate
- Wood veneer
- Metal
- Vinyl
- Painted
- Write-on surfaces/whiteboard
- Fabric
- Custom design
Technical Data
| Classic 51 | Classic 55 | Classic 60 | Classic NRC | |
| TECHNICAL: | ||||
| Acoustic Performance of Installed Systems | Exceptional Soundproofing | Superior Soundproofing | Maximum Soundproofing | Excellent Sound Absorption |
| Acoustic Rating of System | STC 51 (RW 51) | STC 55 (RW 54) | STC 60 (RW 59) | STC 50 (RW 49) NRC up to 0.65 |
| Acoustic Rating of Panels | STC 61 (RW 60) | STC 61 (RW 60) | STC 66 (RW 64) | STC 60 (RW 58) |
| Wall Thickness Panels ≥ 26.5" (673mm) | 11 3/4" (300mm) | |||
| Max. Wall Height | 36' (11000mm) | 36' (11000mm) | 28' (8535mm) | 36' (11000mm) |
| Max. Wall Length | Unlimited | |||
| Weight | 7 lbs/sq.ft. (34.2 kg/m2) | 7.6 lbs/sq.ft. (37.1 kg/m2) | 9.4 lbs/sq.ft. (46 kg/m2) | 7.5 lbs/sq.ft. (36.6 kg/m2) |
| Ceiling Space Required for Storage (approx.*) | 2'-0" to 6'-4" (615mm to 1960mm) | 2'-0" to 6'-4" (615mm to 1960mm) | 2'-0" to 5'-0" (615mm to 1530mm) | 2'-0" to 6'-4" (615mm to 1960mm) |
| Ceiling Pocket Width (approx.*) | 55" to 69" (1400mm to 1750mm) | |||
| Finish Options | Fabric, Vinyl, Paint, Metals, Wood Veneer, Plastic Laminate, Graphics, Murals, White Marker Board, Custom Finish. All Finishes Can Be Mixed-and-Matched. | Acoustically Transparent Fabric Only | ||
| Floor & Wall Tracks | N | N | N | N |
| Back-Up Operation | Y | Y | Y | Y |
| Auto-Reverse | Y | Y | Y | Y |
| Obstruction Safety Sensor | Y | Y | Y | Y |
| Acoustical Performance Warranty: 10-Year (or 5000-Cycle) | Included | |||
| Parts & Labor Warranty: 2-Year (or 5000-Cycle) | Included | |||
| AVAILABLE OPTIONS: | ||||
| LED Lighting | Y | Y | Y | Y |
| Digital Touch Screen Operator Station | Y | Y | Y | Y |
| 10-Year (or 5000-Cycle) Parts Warranty | Y | Y | Y | Y |
| *Each Skyfold wall has custom dimensions made to fit your space. All dimensions are subject to numerous variables. Consult your local Skyfold distributor for project-specific dimensions or restrictions. |
Click to see a full comparison of the whole Skyfold product line.
